SICK CLV62 Series Technical Information

CLV630 CLV631 CLV632
Ethernet Function: Host, AUX
Data transmission rate: 10/100 Mbit/s, half/full duplex
Protocol: TCP/IP, EtherNet/IP, PROFINET Single Port
CAN Function: SICK CAN sensor network (master/slave, multiplexer/server)
Data transmission rate: 20 kbit/s ... 1 Mbit/s
Protocol: CSN (SICK CAN sensor network), CANopen
PROFINET PROFINET Dual Port optional over external fieldbus module CDF600-2
EtherCAT
®
Optional via external fieldbus module CDF600
PROFIBUS Optional via external fieldbus module CDF600-2
DeviceNet Optional over external connection module CDM420 and CMF fieldbus module
Digital inputs 2 (“Sensor 1”, “Sensor 2”), optional 2 additional inputs via CMC600 parameter cloning
module in the CDB650 or CDM420 connection module
Opto-decoupled, V
in
= max. 32 V, reverse polarity protected, can be wired via PNP output,
adjustable debounce time 0 ms ... 10000 ms
Digital outputs 2 (“Result 1”, “Result 2”), optional 2 additional outputs via CMC600 parameter cloning
module in the CDB650 or CDM420 connection module
PNP, I
out
= max. 100 mA, short-circuit protected, adjustable pulse duration (static, 10 ms ...
10000 ms)
Reading pulse Pulse sources for start: Digital inputs “Sensor 1” and/or “Sensor 2”; Command (data inter‐
face), Auto pulse, CAN
Pulse sources for stop: Pulse sources for stop: Reading cycle source, digital inputs “Sensor
1”, “Sensor 2” Command, Timer, Condition (e.g., Good Read)
Optical indicators Not accessible
Acoustic indicator None
Configuration SOPAS ET configuration software, profile programming with bar codes (can be deactivated),
command language, GSD parameterization
Mechanics/Electronics
CLV630 CLV631 CLV632
Connection type Ethernet variant: 2 x round connections (1 x male connector, M12, 17-pin, A-coded, 1 x
female connector, M12, 4-pin, D-coded)
Supply voltage 18 V DC ... 30 V DC, LPS or NEC Class 2, reverse polarity protected
Power consumption
1)
Typically 5 W
Housing Stainless steel
Housing color Unpainted
Window material of the view‐
ing window
Plastic
Mounting elements 2 tapped blind holes M5
Alternative: 4 fixing holes, Ø5.5 mm
Laserwarnschild Lasered on
Safety EN 62368-1: 2014-08
Enclosure rating IP69K (DIN 40050, Part 9)
Test conditions:
•
Water spray volume: 14 l/min ... 16 l/min
•
Water pressure/temperature: 10000 KPa (100 bar) / 80 °C
•
Flat jet nozzle distance: 100 mm ... 150 mm
•
Spray angle: 0°, 30°, 60°, 90°
•
Cycle: 30 seconds per position
•
Rotational speed of test specimen: 5 rpm
TECHNICAL DATA 7
8021479/19ZB/2021-10-29 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
35
Subject to change without notice
