CLV630 CLV631 CLV632
Scanning methods Line scan or raster scan, type-dependent
Sensor type Line scanner, raster scanner
1)
, or line scanner with oscillating mirror. For identifier, see the
type code in the operating instructions
Oscillating mirror functions
•
Fixed (adjustable position), oscillating (variable or fixed amplitude), one-shot
•
Oscillation frequency / period: 0.5 Hz ... 6.25 Hz / 2000 ms ... 160 ms
•
Angle of deflection: -20° ... +20° (adjustable using software)
Orientation of viewing win‐
dow
Front or side, for identifier see type code in operating instructions
Aperture angle Front viewing window: ≤ 50°, side viewing window: ≤ 51.5°
Optical focus Fixed focus
Code resolution 0.2 mm ... 1.0 mm (type-dependent)
Scanning frequency 400 Hz … 1200 Hz
Light source Laser diode, visible red light (λ = 655 nm)
Light spot Oval
MTTF (laser diode) 40000 hours at 25 °C
MTBF 100,000 hours
Laser class Class 2 according to EN/IEC 60825-1:2014. Identical laser class to EN/IEC 60825-1: 2007.
Conforms to 21 CFR 1040.10 except for deviations per Laser Notice No. 50 of June 24, 2007,
and subsequent versions.
Laser power (maximum/aver‐
age)
3.2 mW/ <1.0 mW
Laser pulse duration <300 μs
1)
Raster height approx. 15 mm at a reading distance of 200 mm.
Performance
CLV630 CLV631 CLV632
Readable code structures 1D codes
Bar code types Code 39, Code 128, Code 93, Codabar, EAN, EAN 128, UPC, 2/5 Interleaved, Pharmacode
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading
interval
1)
1 ... 50 (auto-discriminating)
No. of characters per code/
reading interval
Max. 50 characters Maximum 5,000 characters across all bar codes per reading interval, 500
characters for multiplexer function (CAN)
Number of multiple readings 1 ... 99
1)
Reading interval: The time window generated internally by the reading cycle for code detection and evaluation.
NOTE
The bar codes being read must conform to at least quality level C in accordance with ISO/IEC 15416.
Interfaces
CLV630 CLV631 CLV632
Serial (RS-232,
RS-422/-485)
Function: Host, AUX (RS-232 only)
Data transmission rate: 2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
