SICK CLV62 Series Technical Information

CLV640
Light source Laser diode, visible red light (λ = 655 nm)
Light spot Oval
MTTF (laser diode) 40,000 hours at 25 °C
MTBF 100,000 hours
Laser class Class 2 according to EN/IEC 60825-1:2014. Identical laser class for issue EN/IEC
60825-1:2007.
Conforms to 21 CFR 1040.10 except for deviations per Laser Notice No. 50 of June 24, 2007,
and subsequent versions.
Laser power (maximum/aver‐
age)
3.2 mW / < 1.0 mW
Laser pulse duration < 300 μs
1)
Raster height approx. 15 mm at a reading distance of 200 mm
Performance
CLV640
Readable code structures 1D codes
Bar code types Code 39, Code 128, Code 93, Codabar, EAN, EAN 128, UPC, 2/5 Interleaved, Pharmacode
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading
interval
1)
1 ... 50 (auto-discriminating)
No. of characters per code/
reading interval
Max. 50 characters Maximum 5,000 characters across all bar codes per reading interval, 500
characters for multiplexer function (CAN)
Number of multiple readings 1 ... 99
1)
Reading interval: The time window generated internally by the reading cycle for code detection and evaluation
NOTE
The bar codes being read must conform to at least quality level C in accordance with ISO/IEC 15416.
Interfaces
CLV640
Serial (RS-232,
RS-422/-485)
Function: Host, AUX
Data transmission rate: 2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
Ethernet Function: Host, AUX
Data transmission rate: 10/100 Mbit/s, half/full duplex
Protocol: TCP/IP, EtherNet/IP, PROFINET Single Port
CAN Function: SICK CAN sensor network (master/slave, multiplexer/server)
Data transmission rate: 20 kbit/s ... 1 Mbit/s
Protocol: CSN (SICK CAN sensor network), CANopen
PROFINET PROFINET Dual Port optional over external fieldbus module CDF600-2
EtherCAT® Optional via external fieldbus module CDF600
PROFIBUS Optional via external fieldbus module CDF600-2
DeviceNet Optional over external connection module CDM420 and CMF fieldbus module
Digital inputs 2 (“Sensor 1”, “Sensor 2”), 2 additional inputs via CMC600 parameter cloning module in the
CDB650 or CDM420 connection module
Opto-decoupled, V
in
= max. 32 V, reverse polarity protected, can be wired via PNP output,
adjustable debouncing 0 ms ... 10,000 ms
TECHNICAL DATA 7
8021479/19ZB/2021-10-29 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
37
Subject to change without notice
