CLV640
Digital outputs 2 (“Result 1”, “Result 2”), 2 additional outputs via CMC600 parameter cloning module in the
CDB650 or CDM420 connection module
PNP, I
out
= max. 100 mA, short-circuit protected, adjustable pulse duration (static, 10 ms ...
10,000 ms)
Reading pulse Pulse sources for start: Digital inputs “Sensor 1” and/or “Sensor 2”; Command (data inter‐
face), Auto pulse, CAN
Pulse sources for stop: Reading cycle source, digital inputs “Sensor 1”, “Sensor 2” Command,
Timer, Condition (e.g., Good Read)
Optical indicators Not accessible
Acoustic indicator None
Configuration SOPAS ET configuration software, profile programming with bar codes, command language,
GSD parameterization
Mechanics/Electronics
CLV640
Electrical connection Ethernet variant: 2 x round connections (1 x male connector, M12, 17-pin, A-coded, 1 x
female connector, M12, 4-pin, D-coded)
Supply voltage 18 V DC ... 30 V DC, LPS or NEC Class 2, reverse polarity protected
Power consumption Typical 5 W, with unloaded digital outputs
Housing Stainless steel
Housing color Unpainted
Window material of the view‐
ing window
Plastic
Laserwarnschild Lasered on
Safety EN 62368-1: 2014-08
Enclosure rating IP69K (DIN 40050, Part 9)
Test conditions:
•
Water spray volume: 14 l/min ... 16 l/min
•
Water pressure/temperature: 10,000 KPa (100 bar) / 80 °C
•
Flat jet nozzle distance: 100 mm ... 150 mm
•
Spray angle: 0°, 30°, 60°, 90°
•
Cycle: 30 seconds per position
•
Rotational speed of test specimen: 5 rpm
Protection class
(Class 3, EN 61140)
For operation in SELV systems (EN 60950-1) or ES1 systems (EN 62368-1)
Weight
1)
Front viewing window: 890 g, incl. double protective bushing
Side viewing window: 1,230 g, incl. double protective bushing
Device dimensions (L x W x
H)
1)
Side viewing window: 85 mm x 84 mm x 154 mm
Side viewing window (oscillating mirror): 121 mm x 84 mm x 164 mm
Conformities CE.
For further conformities and certificates, see the product page on the Internet at:
www.sick.com/CLV64x
1)
Without connecting cables
2)
See also see "Design", page 13.
7 TECHNICAL DATA
38
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/19ZB/2021-10-29 | SICK
Subject to change without notice
