SICK CLV62 Series Technical Information

1 2
3 3
Figure 1: Viewing window and output aperture of the laser radiation in the IP69K protective
housing
1
CLV62x, CLV63x and CLV64x fixed mount bar code scanner with front viewing window
2
CLV63x and CLV64x fixed mount bar code scanner with oscillating mirror and side viewing
window
3
Viewing window and laser output aperture
NOTE
No maintenance is required to ensure compliance with Laser Class 2.
Warning symbol on the device
The laser warning label is lasered onto the protective housing. The type label is
attached on the housing side of the connections.
Laser output data
In addition to other information, the type label also contains the relevant laser output
data:
•
Laser output power (maximum and average)
•
Wavelength or wavelength range
•
Pulse duration
Example: see "Type label", page 12.
If the device has been installed in an inaccessible location, see the “Features” section
for the relevant device in "Technical data", page 31.
SAFETY INFORMATION 2
8021479/19ZB/2021-10-29 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
9
Subject to change without notice
