lower torques are not secure enough to prevent the multiple light beam safety
de
vice from moving.
$
2,5 Nm -
3 Nm
5 Nm -
6 Nm
b
Mak
e sure that the sender and receiver are aligned correctly. The optical lens sys‐
tems of the sender and the receiver must be located opposite one another (%).
%
b If nece
ssary, use a spirit level to check that the components are parallel (&).
&
Further topics
•
"Sender and r
eceiver alignment", page 40
•
"Minimum distance from the hazardous point", page 15
•
"Minimum distance from reflective surfaces", page 17
•
"Alignment with the QuickFix bracket", page 42
•
"Alignment with the FlexFix bracket or with the upgrade bracket", page 43
