SICK DME4000 User Manual

Chapter 3 Operating Instructions
DME4000
76 © SICK AG • Germany • Subject to change without notice 8014584/ZN33/2017-07
Menu Structure
Hiperface
BusAddress
Add 00 (default)
Setting the Hiperface address (range 0 … 31)
Baudrate
0,6 kBd
Setting the baud rate
1,2 kBd
2,4 kBd
4,8 kBd
9,6 kBd (default)
19,2 kBd
38,4 kBd
Data
8, o, 1
8 data bits
8, e, 1 (default)
1 stopp bit
8, n, 1
Parity choice
Timeout
X1
1*11 / Baud rate
X4 (default)
4*11 / Baud rate
Monitor
On
Off (default)
Period Len
1 Typecode 90H (default)
Corresponding resolution 1 mm
2 Typecode 91H
4 Typecode 92H
8 Typecode 93H
16 Typecode 94H
RS 422
Mode
Request
Data transfer on request only
Continuous
Cyclical data transfer in accordance with the defined baud rate setting
Protocol
Standard
<STX><0x81><0x22><sign><7xBCD><ETX>
CRLF
<sign><7xBCD><CR><LF>
CP0
<sign><7xBCD>
CP1
unused
For a detailed description, see Chapter 9.5 RS-422 Interface.
Note
