CommentBinaryRangeAttributeValue tagContainer tag
Circle's diameter in pixels or
mm depending on attribute
REALcoordUnitDIAMETER
"coordUnit" or configured value
in the Ethernet Result output dia-
log.
0=not found, 1=pass, 2=Out-
side image, 11=Failed on score
value, 12=Failed on diameter
USINT{0, 1, 2,
11, 12}
DECISION
Name attribute required if
more than one Measure dis-
tance exists
any stringnameMEASURE_DIS-
TANCE
Measured distance in pixels or
mm depending on attribute
REALcoordUnitDISTANCE
“coordUnit” or configured value
in the Ethernet Result output dia-
log.
Indicates whether the value in
the distance tag is a valid
USINT{0, 1}VALID
measurement or not. 0=Invalid
1=Valid
0=fail (measure distance could
not be done), 1=pass
USINT{0, 1}DECISION
Name attribute required if
more than one Measure Angle
exist
any stringnameMEAS-
URE_ANGLE
X position of the intersection
point. In “pixels” or “mm” de-
REALcoordUnitX
pending on attribute “co-
ordUnit” or configured value in
the Ethernet Result output dialog.
Y position of the intersection
point. In “pixels” or “mm” de-
REALcoordUnitY
pending on attribute “co-
ordUnit” or configured value in
the Ethernet Result output dialog.
In degrees or radians depend-
ing on attribute “unit” or con-
REAL[0, 180]ANGLE
figured value in the Ethernet
Result output dialog.
Indicates whether the values
in the angle tag are valid
USINT{0, 1, 2}VALID
measurements or not. 0=Inval-
id 1=Valid 2=Intersection out-
side image
0=fail, 1=passUSINT{0, 1}DECISION
Name attribute required if
more than one Edge counter
exist
any stringnameEDGE_COUNT
Chosen feature/edge index.[0, 63]index
Number of found features.USINT[0, 64]FOUND_FEA-
TURES
e
45
©SICK AG • Advanced Industrial Sensors • www.sick.com • All rights reserved
Subject to change without notice
8015726/2013-11
Appendix
Result output formatting
Reference Manual
Inspector PIM
