6 Commissioning
6.1 Simplified illustration
Carry out the following steps based on the example of the dynamic teach:
OUT
OUT
OUT
OUT
2 s
Figure 8: Dynamic teach-in sequence
Table 3: Live measured value display
Value Remission value
0 No remission
3000 Maximum remission with 16 µs response time
9999 Maximum remission with 200 µs response
time
COMMISSIONING 6
