SICK Lector64x Flex - Scope of Delivery

Position Description Characteristic
8 Imager type/color M: Monochrome (black-and-white)
9 Optics/Focusing system C: C-mount thread
E: Electrical focus (dynamic, auto, teach-
auto)
10 Color of the integratable illumination
unit, aperture angle narrow, wide,
medium possible
X: without illumination unit
R: Red/Amber
W: White
B: Blue
11 Focal distance (lens unit) X: No lens installed
H: 54 mm
K: 40 mm
12 Connection variant
1)
A: USB; CAN, serial, IO; Enet 1; Enet 2
(connection variant 1, stand-alone solu‐
tion)
F: CAN IN, IO; CAN OUT, IO; Enet 1; Enet 2;
illumination unit (connection variant 2, for
system)
H: USB; CAN, serial, IO; Enet 1; Enet
2:Fieldbus IN - Profinet; Enet 3:Fieldbus
OUT - Profinet (connection variant 3, with
Dual Port Profinet)
13 IP protection class and viewing win‐
dow
5: IP65, plastic viewing window
6: IP65, glass viewing window
1)
see "Overview of the electrical connections", page 37
3.2 Scope of delivery
Depending on the chosen device version, the scope of delivery of a device will include
the following components:
Table 2: Scope of delivery
No. of
units
Component Remarks
1 Type of device ordered (com‐
plete device or basic device)
Complete device (Lector65x Dynamic Focus):
All required components have already been assem‐
bled at the factory (camera housing and optics
accessories). The optics protection hood is provided
with a device seal.
Basic device (Lector64x Flex, Lector65x Flex) :
Camera housing with C-mount threaded connec‐
tion and individual components for independent
assembly. The light inlet is fitted with a round pro‐
tective cap in the basic version.
All devices:
The M12 and M8 electrical connections are sealed
with a tightly-fastened protective cap.
Without holders and connecting cables.
2 Sliding nut, 5.5 mm deep, with
M5 threaded fixing hole
Alternative mounting option for the device instead
of tapped blind hole. Use in pairs.
1 Hexagon key WAF 2
•
Basic device: For mounting the integratable
VI83I illumination unit from the optional optics
kit.
•
All devices: For opening and closing the cover at
the rear of the device (access to the microSD
card slot).
3 PRODUCT DESCRIPTION
