The sliding nuts can each be inserted into a slot on the side of the housing.
SICK offers prefabricated mounting systems that are optimally suited for mounting the
device, see "Accessories", page 66.
Customer-supplied mounting system
A customer-supplied mounting system must meet the following requirements:
•
The device can be aligned in the X- and Y-axes.
•
The mounting system must be able to bear the weight of the device and connect‐
ing cables without shock.
•
In mounting situations with strong vibrations, it may be necessary to provide shock
mounts.
•
Device mounting options using the four tapped blind holes or two sliding nuts
must be provided.
5.4
Mounting the optics
NOTE
This mounting step is only required if the optics accessory or the Lector6xx Flex (basic
device) device variant has been ordered.
NOTICE
Risk of damage due to electrostatic discharge!
Electrostatic discharge from the human body may damage parts of the illumination unit
or the camera housing.
The illumination variants for lenses with a focal length of 12 mm or 16 mm do not
feature any plastic lenses in front of the LEDs in the round recesses.
■
Take the necessary ESD precautions when assembling the device.
■
Do not insert your fingers into the recesses.
■
Do not touch the open contacts of the electrical connection for the illumination
unit on the camera housing.
NOTE
Possible impairment of image quality!
Dust and fingerprints on optical boundary surfaces can decrease the image quality and
decoding performance of the device.
b
Ensure a dust-free and dry environment when mounting components.
b
Do not touch the image sensor (CMOS) in the light inlet opening of the device or
the glass lenses at either end of the lens unit.
Auxiliary equipment required
•
SW 2 hexagon key (included with delivery)
•
SW 5 socket wrench, Recommendation: as a torque wrench for 65 Ncm
5.4.1 Mounting the lens and illumination
NOTE
When mounting the optics accessories on the camera housing, always ensure that
there is no power to the system.
5 MOUNTING
26
