SICK Lector64x Flex - Mechanics and Electronics

Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xR-MExxxx)
Code resolution ≥ 0.1 mm, depending on lens ≥ 0.12 mm, depending on working
distance
Working range Depending on type, see "Field of view diagrams", page 29
Lens Application-specific, optionally avail‐
able as accessories, see "Acces‐
sories", page 66.
Integrated
For identifier, see see "Type code",
page 13
1)
L
B
= Hazard from blue light.
2)
L
R
= Hazard to the retina of the eye due to heating.
11.2 Mechanics and Electronics
Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xR-MExxxx)
Connection type Connection variant 1 (V2D6xxR-MxxxAx)
•
1 male connector, M12, 17-pin, A-coded (serial, CAN, I/O, voltage supply)
•
2 female connectors, M12, 8-pin, X-coded (Ethernet, 1 GBit/s, P1 with‐
out function)
•
1 female connector, M8, 4-pin (USB)
Connection variant 2 (V2D6xxR-MxxxFx), for systems
•
1 male connector, M12, 5-pin, A-coded (CAN IN)
•
1 female connector, M12, 5-pin, A-coded (CAN OUT)
•
1 female connector, M8, 3-pin (control of external illumination unit)
•
2 female connectors, M12, 8-pin, X-coded (Ethernet, 1 GBit/s, P1 with‐
out function)
Connection variant 3 (V2D6xxR-MxxxHx), with DualPort PROFINET
•
1 male connector, M12, 17-pin, A-coded (serial, CAN, I/O, voltage supply)
•
1 female connector, M12, 8-pin, X-coded (Ethernet, 1 GBit/s)
•
1 female connector, M8, 4-pin (USB)
•
2 female connectors, M12, 4-pin, D-coded (Ethernet, 100 mBit/s)
Supply voltage V
S
DC 24 V ± 20%
Voltage source in accordance with
ES1 and PS2 (EN62368-1) or SELV
and LPS (EN 60950-1) or class 2 (UL
1310) required.
DC 24 V ± 20%
Voltage source in accordance with
ES1 and PS2 (EN 62368-1) or SELV
and LPS (EN 60950-1).
Power consump‐
tion
Operation: 20 W ± 20% typical
1)
Current consump‐
tion
Max. 2.0 A for a typical load of 100 mA on each of the 4 digital outputs
Housing material Aluminum die cast
Housing color Light blue (RAL 5012)
Viewing window
material
Glass or plastic (PMMA), 2 mm thick, with scratch-proof coating: see "Type
code", page 13
Hinged cover
(rear of device)
Material: Plastic
Function: for temporary access to microSD memory card slot
Hinged
2)
, screws (SW2 hexagon key), captive
Enclosure rating IP 65 (EN 60529, EN 60529/A2)
Protection class III
Electrical safety EN 62368-1 (2014-08)
Weight Max. 635 g, without lens and con‐
necting cables
Max. 950 g, model-dependent
11 TECHNICAL DATA
62
O P E R A T I N G I N S T R U C T I O N S | Lector64x/65x Flex, Lector65x Dynamic Focus 8016185/19E9/2020-10-21 | SICK
Subject to change without notice
