SICK Lector64x Flex - Performance; Interfaces

Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xR-MExxxx)
Dimensions (L x
W x H)
142 mm x 89 mm x 46 mm
3)
142.8 mm x 90 mm x 106.1 mm
1)
For digital outputs without load.
2)
When the cover is open, the device no longer conforms with the specified enclosure rating.
3)
Housing only, without lens and protective hood.
11.3 Performance
Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xRMExxxx)
Readable code
structures
1D codes, Stacked, 2D codes
1D code types
(bar code)
GS1-128 / EAN 128, UPC/GTIN/EAN, 2/5 Interleaved, Pharmacode, GS1
DataBar, Code 39, Code 128, Codabar, Code 32, Code 93
Postal codes USPS (Postnet, Planet, USPS4SCB), Australian Post, Dutch KIX Post, Royal
Mail, Swedish Post
2D code types Data Matrix ECC200, GS1 Data Matrix, MaxiCode, QR-Code
Stacked code
types
PDF417
Code qualifica‐
tion
Based on ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 18004
Internal image
memory
512 MB
External image memory on optional microSD memory card (max. 16 GB)
11.4 Interfaces
Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xR-MExxxx)
Ethernet Protocol:
•
TCP/IP
•
EtherNet/IP
Functions:
•
Host (data output of the read result)
•
AUX (Service)
2)
•
FTP (image transfer)
Data transmission rate: 10/100/1,000 MBit/s
MAC address (device-specific), see type label
Serial
1)
RS-232/422
Function: host (data output of the read result)
Data transmission rate: 0.3 kBd ... 115.2 kBd
Serial RS-232
1)
Function: AUX, for Service
2)
Data transmission rate: 57.6 kBd
CAN Protocol: SICK CAN Sensor Network CSN (Master/Slave, Multiplexer/Server)
Function: host (data output of the read result)
Data transmission rate: 20 kBit/s ... 1 MBit/s
PROFIBUS
1)
Function: host (RS-232, data output of the read result)
Type of fieldbus integration: optionally over external CDF600-21xx fieldbus
module
Function blocks for various PLC manufacturers are available online at:
•
www.sick.com/Lector64x
•
www.sick.com/Lector65x
