Type Lector64x Flex (V2D64xR-MCxxxx)
Lector65x Flex (V2D65xR-MCxxxx)
Lector65x Dynamic Focus
(V2D65xR-MExxxx)
USB 2.0 Function: AUX (service)
3)
PROFINET
1)
Function: host (RS-232, data output of read result), PROFINET Single Port,
PROFINET Dual Port
Type of fieldbus integration: PROFINET Single Port, PROFINET Dual Port
optionally over external CDF600-2200 fieldbus module
Function blocks for various PLC manufacturers are available online at:
•
www.sick.com/Lector64x
•
www.sick.com/Lector65x
Digital inputs
1)
Type: 2 physical digital inputs, switching (“Sensor 1”, “Sensor 2”)
Optional 2 additional external digital inputs (software-controlled) via the
CMC600 parameter cloning module in the CDB650-204 or CDM420-0006
connection module
V
in
= max. 32 V, I
in
= max. 5 mA
Opto-decoupled, reverse polarity protected, adjustable debounce time
Configurable digi‐
tal inputs
Encode input, external trigger
Digital outputs
1)
Type: 4 physical digital outputs, switching (“Result1”, “Result2”, “Result3”,
“Result4”)
When using the CDB420: 2 physical digital outputs, switching (“Result1”,
“Result2”)
Optional 2 additional external logical digital outputs (software-controlled) via
optional CMC600 module in the CDB650-204 or CDM420-0006 connection
module
V
out
= V
S
– 1.5 V, I
out
≤ 100 mA
Short-circuit protected, not electrically isolated from the supply voltage
Configurable digi‐
tal outputs
Read confirmation, external illumination control, freely configurable output
condition, “Device Ready”
Reading pulse Digital inputs, free, serial interface, Ethernet, CAN, auto pulse, presentation
mode
Optical indicators 10 status LEDs
10 bar graph LEDs
1 feedback LED for the integratable VI83I ring illumination unit (green), as a
light spot on the code
Acoustic indicator 1 beeper (can be switched off, with functions for indicating a result)
Operating ele‐
ments
2 buttons (select, start, stop functions)
Operator inter‐
faces
Web server
Configuration
tools (parameteri‐
zation)
SOPAS ET
MicroSD memory
card
microSD memory card (flash card) max. 16 GB, optional
Data storage and
retrieval
image and data storage via microSD memory card and external FTP
Maximum
encoder fre‐
quency
1 kHz
External illumina‐
tion control
Via digital output (max. 24 V trigger) or external illumination connection
1)
Does not apply to system variants of type V2D64xR-MCxxFx, type V2D65xR-MCxxFx and V2D65xR-
MExxFx for systems (connection variant 2).
