SICK OD1000 User Manual

•
Alarm (only in Advanced user level)
•
Signal level warning (only in Advanced user level)
•
Edge height change (only in Advanced user level)
> I/O interface > > Q2/Qa output > > Digital output >
Parameter Factory setting
Distance to object > Q2 teach-in:
Q2, Q2 not
-
Distance to object > manual Q2 teach-in:
-1,000.0 mm ... +1,000.0 mm
+400.0 mm
Distance to object > Q2 active status:
High, Low
High
Distance to object > Q2 hysteresis:
0000.0 mm ... +0100.0 mm
+1.0 mm
Distance to object > delay mode:
Off, switch-on delay, switch-off delay, switch-on/switch-off delay, 1
shot
Off
Distance to object > time for delay mode:
0000 ms ... 9,999 ms
100 ms
Window > Q2 teach-in:
Switching point 1, switching point 2
-
Window > manual Q2 teach-in:
Switching point 1, switching point 2
-
Window > Q2 active status:
High, Low
High
Window > Q2 hysteresis:
0000.0 mm ... +0100.0 mm
+1.0 mm
Window > delay mode:
Off, switch-on delay, switch-off delay, switch-on/switch-off delay, 1
shot
Off
Window > time for delay mode:
0000 ms ... 9,999 ms
100 ms
ObSB > Q2 teach-in:
Q2, Q2 not
-
ObSB > manual Q2 teach-in:
-1,000.0 mm ... +1,000.0 mm
+400.0 mm
ObSB > Q2 active status:
High, Low
High
ObSB > Q2 hysteresis:
0000.0 mm ... +0100.0 mm
+1.0 mm
ObSB > Q2 ObSB tolerance
-1,000.0 mm ... +1,000.0 mm
+4.0 mm
ObSB > delay mode:
Off, switch-on delay, switch-off delay, switch-on/switch-off delay, 1
shot
Off
ObSB > time for delay mode:
0000 ms ... 9,999 ms
100 ms
OPERATION VIA DISPLAY 8
8019642/ZJW1/2017-04-03 | SICK O P E R A T I N G I N S T R U C T I O N S | OD1000
45
Subject to change without notice
