Technical specifications
8 Technical specifications
8.1 Process image S3000 PROFINET IO/IOOF Advanced
The process contains data on four monitoring cases and four field sets.
8.1.1 INPUT
Bit Description
0.0 Protective field unoccupied
0.1 Warning field unoccupied
0.2 Simultaneous protective field unoccupied
0.3 Simultaneous warning field unoccupied
0.4 Reset required (protective field)
0.5 Reserved
0.6 Reset required (simultaneous protective field)
Byte 0
0.7 Reserved
1.0 Contamination
1.1 Monitoring case valid
1.2 Monitoring case number – Bit 0
1.3 Monitoring case number – Bit 1
1.4 Reserved
1.5 Reserved
1.6 Reserved
Byte 1
1.7 Reserved
2.0 Reserved
2.1 Reserved
2.2 Reserved
2.3 Reserved
2.4 Reserved
2.5 Reserved
2.6 Reserved
Byte 2
2.7 Reserved
3.0 Reserved
3.1 Reserved
3.2 Reserved
3.3 Reserved
3.4 Reserved
3.5 Reserved
3.6 Reserved
Byte 3
3.7 Reserved
Tab.
7
:
Process image
S3000 PROFINET IO/IO OF
Advanced INPUT
