SICK S3000 PROFINET IO Series User Manual

Addendum Operating Instructions Chapter 8
S3000 PROFINET IO/IOOF
8013291/YY95/2016-02-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 31
Subject to change without notice
Technical specifications
8.2 Process image S3000 PROFINET IO/IOOF Professional
T
he process contains data on eight monitoring cases and eight field sets.
8.2.1 INPUT
Bit Description
0.0 Protective field unoccupied
0.1 Warning field unoccupied
0
.2 Simultaneous protective field unoccupied
0.3 Simultaneous warning field unoccupied
0.4 Reset required (protective field)
0.5 Reserved
0.6 Reset required (simultaneous protective field)
Byte 0
0.7 Reserved
1.0 Contamination
1.1 Monitoring case valid
1.2 Monitoring case number – Bit 0
1.3 Monitoring case number – Bit 1
1.4 Monitoring case number – Bit 2
1.5 Monitoring case number – Bit 3
1.6 Reserved
Byte 1
1.7 Reserved
2.0 Reserved
2.1 Reserved
2.2 Reserved
2.3 Reserved
2.4 Reserved
2.5 Reserved
2.6 Reserved
Byte 2
2.7 Reserved
3.0 Reserved
3.1 Reserved
3.2 Reserved
3.3 Reserved
3.4 Reserved
3.5 Reserved
3.6 Reserved
Byte 3
3.7 Reserved
Tab.
9
:
Process image
S3000 PROFINET IO/IO OF
Professional INPUT
