SICK S3000 PROFINET IO Series User Manual

Chapter 8 Addendum Operating Instructions
S3000 PROFINET IO/IOOF
36 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8013291/YY95/2016-02-05
Subject to change without notice
Technical specifications
8.5 Data sheet
C
ontrary to the technical data described in the original operating instructions “S3000
safety laser scanner”, described in the following are the technical data that are different or
additional to the technical data for the safety laser scanners in the S3000 family.
Minimum Typical Maximum
General data
PFHd (T
amb
= 25 °C)
(mean probability of a dangerous
failure per hour)
80 × 10
–9
Protective field range
Short Range
Medium Range
Long Range
4.00 m
5.50 m
7.00 m
Range of performance
Advanced
Professional
4 protective and warning fields (field sets)
8 protective and warning fields (field sets)
Electrical data
Electrical protection class III (VDE 0106, EN 60950)
Bus connection 2 standard PROFINET IO sockets for push-pull plug
connectors with metal housing (RJ845 or SCRJ)
Supply connection Plug-in device connection plug with …
 cable gland for cable diameter of 5–10 mm
 screw type terminal connection for max. wire
cross-section 1.5 mm
2
 integrated configuration memory
Levels for input information:
Restart
4)
Initialising
Stand-by
Monitoring case switching
4)
Activated on low-high transition
Activated on low-high transition
Activated on permanently high
Static (complementary)
Optical fiber
Wave length of the transmitter
(EN 72471)
650 nm
Diameter of the fiber-optic cable of
the POF cables
980 µm 1000 µm
Cable length 50 m
Line attenuation
5)
12 dB
4)
Fail-safe input signals are required.
5)
Pay attention to the mounting and wiring instructions of the manufacturer of the connectors and cables, in
particular with regard to the number of bending radiuses.
Tab.
11
:
Data sheet
S3000 PROFINET IO/IO OF
