Chapter 8 Addendum Operating Instructions
S3000 PROFINET IO/IOOF
32 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8013291/YY95/2016-02-05
Subject to change without notice
Technical specifications
Bit Description
4.0 Reserved
4.1 Reserved
4.2 Reserved
4.3 Reserved
4.4 Reserved
4.5 Reserved
4.6 Reserved
Byte 4
4.7 Reserved
5.0 Reserved
5.1 Reserved
5.2 Reserved
5.3 Reserved
5.4 Reserved
5.5 Reserved
5.6 Reserved
Byte 5
5.7 Reserved
8.2.2 OUTPUT
Bit Description
0.0 Monitoring case switching A1
0.1 Monitoring case switching A2
0.2 Monitoring case switching B1
0.3 Monitoring case switching B2
0.4 Monitoring case switching C1
0.5 Monitoring case switching C2
0.6 Monitoring case switching D1
Byte 0
0.7 Monitoring case switching D2
1.0 Reset the protective field
1.1 Reserved
1.2 Reset the simultaneous protective field
1.3 Reserved
1.4 Stand8by
1.5 Initialising
1.6 Reserved
Byte 1
1.7 Reserved
Tab.
10
:
Process image
S3000 PROFINET IO/IO OF
Professional OUTPUT

SICK S3000 PROFINET IO Series Specifications

General

Interfaces	PROFINET IO
Protection class	IP65
Safety integrity level	SIL2 (IEC 61508)
Operating temperature	0 °C ... +50 °C
Supply voltage	24 V DC
Performance level	PL d
Type	Laser scanner
Protective field range	0.1 m to 3 m
