SICK S3000 PROFINET IO Series User Manual

Addendum Operating Instructions Chapter 8
S3000 PROFINET IO/IOOF
8013291/YY95/2016-02-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 29
Subject to change without notice
Technical specifications
Bit Description
4.0 Reserved
4.1 Reserved
4.2 Reserved
4.3 Reserved
4.4 Reserved
4.5 Reserved
4.6 Reserved
Byte 4
4.7 Reserved
5.0 Reserved
5.1 Reserved
5.2 Reserved
5.3 Reserved
5.4 Reserved
5.5 Reserved
5.6 Reserved
Byte 5
5.7 Reserved
8.1.2 OUTPUT
Bit Description
0.0 Monitoring case switching A1
0.1 Monitoring case switching A2
0.2 Monitoring case switching B1
0.3 Monitoring case switching B2
0.4 Reserved
0.5 Reserved
0.6 Reserved
Byte 0
0.7 Reserved
1.0 Reset the protective field
1.1 Reserved
1.2 Reset the simultaneous protective field
1.3 Reserved
1.4 Stand8by
1.5 Initialising
1.6 Reserved
Byte 1
1.7 Reserved
Tab.
8
:
Process image
S3000 PROFINET IO/IO OF
Advanced OUTPUT
