SICK TR4 Direct User Manual

OSSD 1
V
t
1
2
V
t
3
2
OSSD 2
2 2
Figure 7: Course of the OSSD test over time
1
Usually every 20 ms.
1
Test pulse interval About every 45 ms
2
Test pulse width 160 μs
3
Test pulse deviation
9.3 Dimensional drawings
9.3.1 Sensor dimensional drawing
67,06
2,03
M18 × 1
Figure 8: Sensor dimensional drawing (mm)
9.3.2 Actuator dimensional drawing
15,42
13,72
15,87
36,47
3,17
19,81
36,47
15,87
13,72
Ø 4,57
Figure 9: M18 actuator dimensional drawing (mm)
16,84
19,81
22,22
48,92
3,17
30,40
48,92
22,22
19,81
Ø 4,57
Figure 10: M30 actuator dimensional drawing (mm)
TECHNICAL DATA 9
8022968/15V1/2019-11-22 | SICK O P E R A T I N G I N S T R U C T I O N S | TR4 Direct Cylindrical
25
Subject to change without notice
