10 Ordering information
10.1 TR4 Direct ordering information with secure switch-on distance S
ao
= 15 mm
Scope of delivery: Sensor, actuator, operating instructions
Table 10: Safety switch part numbers
Coding Sensor connection type Type code Part number
Universally coded Cable 3 m, PVC TR4-SAM03PB 6070787
Cable 10 m, PVC TR4-SAM10PB 6070788
Cable with male connector,
M12, 8-pin
TR4-SAM01CB 6070789
Cable with male connector,
M12, 5-pin
TR4-SAM02CB 6070799
Uniquely coded Cable 3 m, PVC TR4-SAU03PB 6070790
Cable 10 m, PVC TR4-SAU10PB 6070791
Cable with male connector,
M12, 8-pin
TR4-SAU01CB 6070792
Cable with male connector,
M12, 5-pin
TR4-SAU02CB 6070800
10.2 TR4 Direct ordering information with secure switch-on distance S
ao
= 25 mm
Scope of delivery: Sensor, actuator, operating instructions
T
able 11: Safety switch part numbers
Coding Sensor connection type Type code Part number
Universally coded Cable 3 m, PVC TR4-SBM03PB 6070793
Cable 10 m, PVC TR4-SBM10PB 6070794
Cable with male connector,
M12, 8-pin
TR4-SBM01CB 6070795
Cable with male connector,
M12, 5-pin
TR4-SBM02CB 6070801
Uniquely coded Cable 3 m, PVC TR4-SBU03PB 6070796
Cable 10 m, PVC TR4-SBU10PB 6070797
Cable with male connector,
M12, 8-pin
TR4-SBU01CB 6070798
Cable with male connector,
M12, 5-pin
TR4-SBU02CB 6070802
10 ORDERING INFORMATION
26
O P E R A T I N G I N S T R U C T I O N S | TR4 Direct Cylindrical 8022968/15V1/2019-11-22 | SICK
Subject to change without notice
