12 Accessories
12.1 Connectivity
Table 13: Connecting and connection cables
Part Type code Part number
4-wire connecting cable
W
ith female connector, M12, 4-pin, straight/stripped
2 m YF2A14-020VB3XLEAX 2096234
5 m YF2A14-050VB3XLEAX 2096235
10 m YF2A14-100VB3XLEAX 2096236
8-wire connecting cable
W
ith female connector, M12, 8-pin, straight/stripped
2 m YF2A18-020UA5XLEAX 2095652
5 m YF2A18-050UA5XLEAX 2095653
10 m YF2A18-100UA5XLEAX 2095654
5-wire connecting cable
W
ith female connector, M12, 5-pin, straight/stripped
2 m YF2A15-020VB5XLEAX 2096239
5 m YF2A15-050VB5XLEAX 2096240
10 m YF2A15-100VB5XLEAX 2096241
4-wire connection cable
W
ith female connector, M12, 4-pin, straight/male connector, M12, 4-pin, straight
2 m YF2A14-020VB3M2A14 2096599
5 m YF2A14-050VB3M2A14 2096600
10 m YF2A14-100VB3M2A14 2096601
8-wire connection cable
W
ith female connector, M12, 8-pin, straight/male connector, M12, 8-pin, straight
2 m YF2A18-020UA5M2A18 2096033
5 m YF2A18-050UA5M2A18 2096034
10 m YF2A18-100UA5M2A18 2096035
5-wire connection cable
W
ith female connector, M12, 5-pin, straight/male connector, M12, 5-pin, straight
2 m YF2A15-020UB5M2A15 2096009
5 m YF2A15-050UB5M2A15 2096010
10 m YF2A15-100UB5M2A15 2096011
Table 14: T-connector and end connector
Part Type code Part number
T-connector for series connection of TR4 Direct STR-XXA 5339609
End connector for series connection in connec‐
t
ion with T-connector MLP1-XXT
MLP1-XXT 1078201
12.2 Mounting accessories
Table 15: Mounting brackets/plates
Part Material Type code Part number
Mounting bracket, M18
t
hread
Steel, zinc-plated BEF-WN-M18 5308446
12 ACCESSORIES
28
O P E R A T I N G I N S T R U C T I O N S | TR4 Direct Cylindrical 8022968/15V1/2019-11-22 | SICK
Subject to change without notice
