6 Application examples
The examples shown are only provided as an aid for your planning. You may need to
consider additional protection measures for your application.
6.1 Application with one V200/V300
If the necessary protective field dimensions can be realised using a single V200/V300,
then mount the camera on a corner of the frame or in a corner of the frame. Apply the
reflective tape to the opposite sides.
Note
small protective field
(1 × V200/V300)
tape
