SICK V200 - Technical specifications; Data sheet

Chapter 11 Operating Instructions
V200/V300
52 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012227/YT87/2016-03-29
Subject to change without notice
Technical specifications
11 Technical specifications
11.1 Data sheet
Minimum Typical Maximum
General system data
Protective field dimensions See section 4.1 “Checking the dimensions of the
protective field” on page 18ff.
Type
V200 Work Station Extended 2 (IEC 61 496-1, IEC/TR 61 496-4)
V300 Work Station Extended 3 (IEC 61 496-1, IEC/TR 61 496-4)
Safety integrity level
2)
V200 Work Station Extended SIL1 (IEC 61 508)
V300 Work Station Extended SIL2 (IEC 61 508)
SIL claim limit
2)
V200 Work Station Extended SILCL1 (EN 62 061)
V300 Work Station Extended SILCL2 (EN 62 061)
Category
V200 Work Station Extended 2 (EN ISO 13 849-1)
V300 Work Station Extended 3 (EN ISO 13 849-1)
Performance Level
2)
V200 Work Station Extended PL c (EN ISO 13 849-1)
V300 Work Station Extended PL d (EN ISO 13 849-1)
Test rate 50 ¹/s (EN ISO 13 849-1)
Demand rate
3)
30 ¹/min (EN ISO 13 849-1)
PFHd (mean probability of a
dangerous failure per hour)
5.6 × 10
–9
T
M
(mission time) 20 years (EN ISO 13 849)
Protection class III (EN 50 178)
Enclosure rating IP 54 (EN 60 529)
Resolution 20 mm, 24 mm or 30 mm
Field of view 103° ± 3°
Ambient operating temperature –5 °C +50 °C
Storage temperature –25 °C +70 °C
(′ 24 h)
Humidity, taking into account the
operating temperature range
IEC 61 496-1, section 5.1.2 and section 5.4.2 as
well as IEC/TR 61 496-4, section 5.4.2
Air humidity (non-dewing) 15 % 95 %
Sinusoidal vibration 5 g, 10–55 Hz (EN 60 068-2-6)
Shock resistance 10 g, 16 ms (EN 60 068-2-27)
2)
For detailed information on the safety design of your machine/system, please contact your local SICK
representative.
3)
For V200 Work Station Extended the following applies: Between two demands for a safety-related reaction
from the device, at least 100 internal or external tests must be performed.
Tab.
15
:
Data sheet
V200/V300
