SICK V200 - Page 53

Operating Instructions Chapter 11
V200/V300
8012227/YT87/2016-03-29 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 53
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Lighting
Wavelength 850 nm
Occular safety Photobiologically harmless (IEC 62 471-7)
Housing
Material Aluminium die cast
Dimensions See section 11.2 “Dimensional drawings” on
page 56.
Total weight 0.355 kg
Reflective tape (length × width)
for resolution:
20 mm 1.00 m × 37 mm
24 mm 1.20 m × 37 mm
30 mm 1.50 m × 48 mm
Power-up delay after connecting
the supply voltage
6 s
Electrical data
Supply voltage V
S
at the device
(SELV)
4)5)
19.2 V 24 V 28.8 V
Permissible cable resistance on
the supply cable
1 Ω
Residual ripple
6)
°5 %
Operating current
at 24 V without output load 165 mA
with maximum output load 690 mA
Power consumption
at 24 V without output load 4 W
with maximum output load 19 W
Electrical connection M12 × 8 (see section 5.1 on page 32)
Cable length for wire cross-section
0.25 mm²
7.5 m
Synchronisation Electrical (see section 5.1 on page 32)
4)
To meet the requirements of the relevant product standards (e.g. IEC 61 496-1), the external voltage supply
for the devices (SELV) must be able to bridge a brief mains failure of 20 ms. Power supplies according to
EN 60 204-1 satisfy this requirement. Suitable power supplies are available as accessories from SICK (see
section 12.2 “Accessories” on page 59).
5)
A fuse rated maximum 2 A shall be installed in the isolated 24 V DC power supply circuit to the device in order
to limit the available current.
6)
Within the limits of V
S
.
