Chapter 11 Operating Instructions
V200/V300
54 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012227/YT87/2016-03-29
Subject to change without notice
Technical specifications
Minimum Typical Maximum
External device monitoring (EDM)
input
Resistance HIGH 2 kΩ
Capacitance 15 nF
Voltage (IEC 61 131-2)
HIGH 11 V 24 V 30 V
LOW –3 V 0 V 5 V
Static current 6 mA 15 mA
Reset/restart input (RESTART)
Resistance HIGH 2 kΩ
Capacitance 15 nF
Voltage (IEC 61 131-2)
HIGH 11 V 24 V 30 V
LOW –3 V 0 V 5 V
Static current 6 mA 15 mA
Actuating time control switch
input
120 ms
Teach-in/synchronisation
(TEACH/SYNCH) input
The input must be operated by a key-operated
switch (contact).
Resistance HIGH 2 kΩ
Capacitance 15 nF
Voltage HIGH 11 V 24 V 30 V
Static current 6 mA 15 mA
