NOTE
Disposal of batteries, electric and electronic devices
•
According to international directives, batteries, accumulators and electrical or
electronic devices must not be disposed of in general waste.
•
The owner is obliged by law to return this devices at the end of their life to the
respective public collection points.
•
WEEE: This symbol on the product, its package or in this document,
indicates that a product is subject to these regulations.
11 Technical data
11.1 Technical specifications
The “Technical Data” section contains only an extract of the technical data of the sensor.
The complete technical data can be found on the homepage www.sick.com under the part number of the sensor.
Features
Sensing range
WLG4S
Min. sensing range 0 m
Sensing range max. 7.1 m
Reference reflector PL80A
Recommended sensing range for the best performance 0 m … 5 m
Maximum distance range from reflector to sensor (operating
reserve 1)
7.1 m
Recommended distance range from reflector to sensor (operating
reserve 3.75)
5.0 m
Emitted beam
WLG4S
Light sender PinPoint-LED
Type of light Sichtbares Rotlicht
Light spot size / distance Ø 150 mm (5 m)
Communication interface
Table 12: Communication interface
IO-Link
WLG4S
IO-Link 1.1
Data transmission rate 38.4kbit/s (COM2)
Electrical data
WLG4S
Supply voltage U
B
DC 10 ... 30 V
1)
Ripple ≤ 5 VSS
Current consumption 25 mA
2)
Protection class III
1)
Limit values
Reverse polarity protected U
B
connections
Residual ripple max. 5V
ss
2)
Without load. For U
B
= 24 V.
