WLL180T Photoelectric sensors for fiber-optic cables
12 SICK 2010-08-02
Subject to change without notice
Response time switching frequency range
HiGh: 16 μs 31.25 kHz short
FASt: 70 μs 7.1 kHz reduced
Stnd: 250 μs 2 kHz standard (factory setting)
LonG: 2 ms 250 Hz high
SuPr: 8 ms 62.5 Hz super long
2.2 Response time
2. Operating mode Configuring
active
3. In the basic menu, select
required mode by pressing
the arrow keys
4. In the basic menu, select
required mode by pressing
the arrow keys
–
+
5. Response time is shown on
the display
–
+
6. Select between high-preci-
sion setting (LonG), stand-
ard setting (Stnd), fastest set-
ting (FASt), high speed setting
(HiGh) and super long setting
(SuPr) by pressing the arrow
keys
7. Finish selection with Mode key
9. Finish selection with Mode key
8. Select ending the adjustment
(End)
–
+
1. Press Mode key for 2 s
Configuring
