SICK WLL180T User Manual

WLL180T Photoelectric sensors for fiber-optic cables
2010-08-02 SICK 19
Subject to change without notice
3.4 Reverse display
This function reverses the display (display upside-down). This
offers a good readability also in difficult mounting positions.
14. Finish selection with Mode key
13. Select ending the adjustment
(End)
–
+
11. Close Expert mode with
arrow key
–
+
12. Finish selection with Mode key
2. Operating mode Configuring
active
6. In Expert mode, select
required mode by pressing
the arrow keys
7. Turn is shown on the display
8. Press Mode key
9. Select between “oFF” and “on”
by pressing the arrow keys
10. Finish selection with Mode key
–
+
–
+
5. Press Mode key
1. Press Mode key for 2 s
3. In the basic menu, select
Expert mode by pressing the
arrow keys
4. Expert mode is shown on
the display
–
+
Configuring
