WLL180T Photoelectric sensors for fiber-optic cables
2010-08-02 SICK 15
Subject to change without notice
2.5 Reset
All operating modes are reset to the factory setting
“as-delivered ex works”.
Factory settings:
Switching mode: ON light-switching
Response time: Standard = 250 μs
Time stage: Off
Set display value to zero: Off
Display: Numeric display
Energy-saving mode: Off
Reverse Display: Off
Hysteresis setting: Standard = 5
Input setting: Teach-in input
ASC setting: Off
Power of the sender LED: Standard =
highest power
Keylock: Level 1
2. Operating mode Configuring
active
4. In the basic menu, select
required mode by pressing
the arrow keys
5. Reset is shown on the display
6. Press Mode key
7. Select between “no” and “YES”
by pressing the arrow keys
8. Finish selection with Mode key
–
+
–
+
9. Select ending the adjustment
(End)
–
+
10. Finish selection with Mode key
3. Press Mode key
1. Press Mode key for 2 s
Configuring
