SICK WLL180T User Manual

WLL180T Photoelectric sensors for fiber-optic cables
16 SICK 2010-08-02
Subject to change without notice
The current reception value is set to zero.
Adjusted switching threshold values are adapted.
on: Function active
oFF: Function deactivated (factory setting)
2. Operating mode Configuring
active
3. In the basic menu, select
Expert mode by pressing the
arrow keys
4. Expert mode is shown on
the display
Configuring
–
+
9. Select between “on” and “oFF”
by pressing the arrow keys
–
+
3.1 Set display value to zero
5. Press Mode key
10. Finish selection with Mode key
8. Press Mode key
6. In Expert mode, select
Set to zero by pressing the
arrow keys
7. Set to zero is shown on
the display
–
+
11. Close Expert mode with
arrow key
–
+
12. Finish selection with Mode key
13. Select ending the adjustment
(End)
14. Finish selection with Mode key
–
+
1. Press Mode key for 2 s
