SICK WLL180T User Manual

WLL180T Photoelectric sensors for fiber-optic cables
24 SICK 2010-08-02
Subject to change without notice
2. Operating mode Configuring
active
4. In the basic menu, select
Expert mode by pressing the
arrow keys
5. Expert mode is shown on
the display
6. Press Mode key
7. In Expert mode, select ASC
setting by pressing the arrow
keys
8. ASC setting is shown on
the display
–
+
–
+
on: automatically adapting switching threshold to environment,
oFF: switch off ASC (factory setting).
10. Select between “on” and
“oFF” by pressing the arrow
keys
3.9 ASC setting
–
+
9. Press Mode key
3. Press Mode key
1. Press Mode key for 2 s
12. Close Expert mode with arrow
key
–
+
13. Finish selection with Mode key
14. Select ending the adjustment
(End)
15. Finish selection with Mode key
–
+
11. Finish selection with Mode key
Configuring
