Compact Operating Instructions in accordance with EN 61010-1 and EN 60079-0
28 A5E45779144002-01, 09/2018
Parts in gas path wetted by sample gas
19" rack unit
Bench-top unit (only IR + ec O
2
)
With hoses
Condensation trap at gas
inlet
-- PA6 (polyamide)
Condensation trap
--
PE (polyethylene)
Gas connections 6 mm
PA6 (polyamide)
PA6 (polyamide)
Gas connections ¼"
Stainless steel 1.4571
Stainless steel 1.4571
Hose
FKM
FKM
Pressure switch
PTFE + PA6 (polyamide)
PTFE + PA6 (polyamide)
Flowmeter
Borosilicate glass/steel 1.4878
Borosilicate glass/steel 1.4878
Elbows/T-pieces
PA6
PA6
Internal pump (optional) PVDF/PTFE/FKM/HD-
PE/stainless steel 1.4571
PVDF/PTFE/FKM/HD-PE/stainless
steel 1.4571
Solenoid valve (optional) FKM/PA6/stainless
steel 1.4310/1.4305
FKM/PA6/stainless
steel 1.4310/1.4305
Safety condensation trap PA66/NBR/PA6 PA66/NBR/PA6
Analyzer chamber
● Body IR
● Body UV
● Lining
● Nozzle
● Window IR
● Window UV
● Adhesive
● O-ring
Aluminum
Aluminum anodized,
color: Sanodal ® Deep Black
Aluminum
Stainless steel 1.4571
CaF
2
Synthetic quartz glass
Epoxy resin-based adhesive
FKM
Aluminum
--
Aluminum
Stainless steel 1.4571
CaF
2
--
Epoxy resin-based adhesive
FKM
Piped (only
possible without
pump)
Gas connections 6 mm/¼"
Stainless steel 1.4571
Pipes
Stainless steel 1.4571
Analyzer chamber (only IR)
● Body
● Lining
● Nozzle
● Window
● Adhesive
● O-ring
Aluminum
Aluminum
Stainless steel 1.4571
CaF
2
Epoxy resin-based adhesive
FKM
Aluminum
Aluminum
Stainless steel 1.4571
CaF
2
Epoxy resin-based adhesive
FKM
7.3
Technical specifications ULTRAMAT 6E and ULTRAMAT channel in
ULTRAMAT/OXYMAT 6E
Enclosure
Weight Approx. 15 kg with one IR channel
approx. 21 kg with two IR channels
Dimensions
483 mm x 385 mm x 177 mm (W x D x H)
Electrical characteristics
Power consumption
• 1-channel unit
• 2-channel unit
Approx. 40 VA
approx. 70 VA
