Compact Operating Instructions in accordance with EN 61010-1 and EN 60079-0
30 A5E45779144002-01, 09/2018
Parts in gas path wetted by sample gas
Angle pieces
FKM
Pressure switch sample gas
Diaphragm
FKM
Enclosure
PA 6.3 T
7.4
Technical specifications OXYMAT 6E, OXYMAT channel in
OXYMAT/ULTRAMAT 6E and OXYMAT 61
Enclosure
Weight
Approx. 13 kg
Dimensions
483 mm x 385 mm x 172 mm (W x D x H)
Electrical characteristics
Power consumption (analyzer)
Approx. 45 VA
Fuse ratings
• 100 ... 120 V
• 200 ... 240 V
1T/250
0.63T/250
Gas inlet conditions
Permissible sample gas pressure 800 to 1200 hPa absolute (with external reference gas supply),
atmospheric pressure (with built-in pump)
Sample gas flow
18 to 60 l/h (0.3 to 1 l/min)
Sample gas temperature
0 to 50 °C
Sample gas moisture content
< 90% RH
Parts in gas path wetted by sample gas
Standard devices
Gas path with tubes
Gas feedthrough
Stainless steel 1.4571
Hose
FKM
Hose coupling
PA 6
Restrictor
PTFE
Measuring chamber
Stainless steel 1.4571 or Ta (OXYMAT 6)
Pipe gas path (OXYMAT 6)
Gas feedthrough
Hastelloy C22 or Ti or stainless steel 1.4571
Pipe
Hastelloy C22 or Ti or stainless steel 1.4571
Measuring chamber
Stainless steel 1.4571 or Ta (OXYMAT 6)
Special applications
Pipe gas path (OXYMAT 6)
Gas feedthrough
Hastelloy C22
Pipe/nozzle
Hastelloy C22
Measuring chamber
Hastelloy C22
Gaskets (O-rings)
Material according to specification
Further designs upon request
Options
Flowmeter
Measurement pipe
Duran glass
Variable area
Duran glass
Suspension boundary
PTFE
Angle pieces FKM
Pressure switch sample gas Diaphragm FKM
