Terminal Lugs Specification
Table 2-1 Terminal Lugs Specifications
Terminal Blocks Cable Type/Cable Specifications Manufacturer/Part Number Torque
Required
Current inputs TE connectivity PIDG series insulated tin
plated crimp ring terminal, M3.5 stud
size, 2.6 mm
2
to 6.6 mm
2
, 12 AWG
TE Connectivity Mfr. Part No.
2-327960-1 or equivalent
1.0 Nm
Auxiliary supply Insulated tin plated crimp pin connector,
2.6 mm
2
to 6.6 mm
2
, 12 AWG to 10 AWG
End sleeve
3D-8011H or equivalent
0.5 Nm to 0.6
Nm
Rear communica-
tion port
Pin type lug/1.5 mm
2
control cable
End sleeve
3D-8011H or equivalent
0.5 Nm to 0.6
Nm
Front communica-
tion port
USB, type B Tyco/974329-1 or equivalent -
Binary input/binary
output/pulse
output/flag output
Insulated tin plated crimp pin connector,
2.6 mm
2
to 6.6 mm
2
, 12 AWG to 10 AWG
End sleeve
3D-8011H or equivalent
0.5 Nm to 0.6
Nm
Ground terminal Tin plated crimp ring terminal, M3 stud
size, 4 mm
2
to 6 mm
2
, 12 AWG to 10
AWG
RS Stock No. 613-9334 or
equivalent Mfr. Part no.
RVY5-3.2
0.5 Nm to 0.6
Nm
2.5
Installing the Device
2.5 Terminal Lugs Specification
26 Reyrolle, Operating, Manual
C53000-B7040-C101-1, Edition 08.2020
