Installing Transparent Front Cover
i
i
NOTE
The transparent front cover accessory is only available for the 7SR4503/7SR4504 reduced housing height
version.
Table 3-1 Fastener Kit 1 Specification for Transparent Front Cover
Fastener Kit 1 Specifications Quantity
M4x20 Round Stainless-Steel Stud 4
Lock Washer 4
Nut 4
Table 3-2 Fastener Kit 2 Specification for Transparent Front Cover
Fastener Kit 2 Specifications Quantity
M4 Knurled Screw 4
²
Remove the 4 M4x20 Pan Philips stainless-steel screws and the 4 nuts from the 7SR45 Argus Relay and
the protection panel/cubicle.
3.2
Handling of the Device
3.2 Installing Transparent Front Cover
