6. Electrical function test
Item No. Commissioning Step Performed Yes No Remarks
6.1 Grounding system continuity test
6.2
Insulation test has been performed with R > 1000W/V of the rated
operational voltage. Faults have been located and eliminated.
Wire
L1 – L2
L1 – L3
L2 – L3
L1 – PEN
L1 – PEN
L1 – PEN
PE – PEN
6.3 Control voltage present
6.4 Alarm starting checked
6.5 Release functions checked
6.6 Measuring instruments and indicators checked
6.7 Ground-fault detection checked
6.8 Electrical interlocks of functional units checked
– of device combinations
– of circuit breakers
– transfer trip connection from medium voltage
– others
6.9 Tested after connection to supply
Phase sequence check right
left
Commissioning company: ................................................... Name: ....................................
Commissioning department: ..................................................
Date: ..............................…................. Signature: ....................................
