ARCADIS Orbic Quick Guide
NaviLink 2D/3D
127
Procedure
Preparation
Set up the C-arm and the navigation sys-
tem and start both systems.
Enter the patient data.
Establish direct communication with the
aid of a network cable.
The readiness of the C-arm is indicated
by an icon in the status bar of the
Examination task card (1).
Select the examination parameters.
Procedure
Release radiation.
The image appears in the References
task card at the monitor trolley.
Check the setting and image quality.
If necessary, repeat the exposure.
Confirm the selection of the image at the
navigation system by clicking Request
image.
The image is automatically transferred
from the C-arm to the navigation system.
Make further exposures until you have
reached the desired number of images for
navigation.
Final steps
If necessary, dismantle the C-arm and
take it out of the room.
