ARCADIS Orbic Quick Guide
Examination Procedure
39
Fluoro Loop/LSH (option)
In the fluoroscopy, subtraction and Roadmap
modes, scenes can be reviewed and stored
(Last Scene Hold) during the examination.
Reviewing a scene
After radiation is ended, the buttons for con-
trolling the scene review are displayed.
(1) Start
(2) Stop
(3) Previous frame
(4) Next frame
Storing the scene
As soon as the scene has been reviewed, it
can be stored.
✧ Select Patient > Save LSH Scene or
press function key F9 on the keyboard.
➭ The current scene (up to 120 images) is
stored in the local database.
Ending the examination
✧ Call up Patient > End Exam in the main
menu.
➭ Patient and examination data are deleted
from the Examination card.
➭ If Automatic transfer is activated, the
examination images are automatically
saved to CD-R or sent to the information
system (option).
