ARCADIS Orbic Quick Guide
3D option
65
Overview
The 3D option consists essentially of motor
control of the orbital movement which can
be switched in optionally and a task card for
3D image reconstruction and visualization.
Areas of application
The 3D option is suitable for intraoperative
use in the following areas:
❏ Bones and joints of the upper and lower
extremities
❏ Entire spine
❏ Hip and pelvic region
❏ Facial bones
NaviLink-3D (option)
NaviLink-3D enables the use of different opti-
cal navigation systems. For registration, the
position and orientation of the 3D data set are
transferred with a matrix "Ma".
(1) Navigation marker ring
(registration unit)
(2) Pointer
(3) 3D data set (cube)
