ARCADIS Orbic Quick Guide
Product Overview
13
C-arm system
C-arm
(1) Image intensifier
(2) X-ray tube
(3) Emergency stop
(4) Hand switch
(5) Steering lever
(6) Holder for footswitch
(7) Locking brake
Steering lever, brakes
(5) Steering lever
❏ Steering lever straight:
Move C-arm system in any direction
❏ Steering lever diagonal:
Move C-arm in transverse direction,
e.g. parallel to the table
(7) Locking brake
❏ Locking brake released:
Move C-arm system
