ARCADIS Orbic Quick Guide
Examination Procedure
22
To select parameters, use the mouse to
click the monitor trolley.
(3)
(1)
(2)
(5)
(4)
(7)
(6)
If the optional laser light localizer is avail-
able, the object should be positioned with
the laser light localizer, i.e. without radia-
tion, as far as possible for reasons of radia-
tion protection.
(8)
(9)
(10)
