ARCADIS Orbic Quick Guide
3D option
87
Start orientation of image series
✧ If it is not already displayed, open the
Fusion Registration dialog using this
button (1).
✧ Select a registration matrix (2):
❏ Default
if there is no suitable default orientation
❏ User-defined
if a suitable orientation has already been
saved as a matrix
✧ Select the desired orientation mode:
(3) Selection points
Anchor the image series to appropriate
reference points
(4) Visual Registration
Optical (manual) superimposition
(5) Surface Matching
Orientation based on set threshold values
depending on the tissue structure
(6) Auto Registration
Automatic superimposition
➭ The display of the image area depends on
the mode. The corresponding tools are
displayed in the Fusion Registration dia-
log.
