Key switch for desk call station PTO2002/3
-
A1
Operating functions PTO2002/3-A1
9
34 | 57 A6V10430571_en--_c
9 Key switch for desk call station
PTO2002/3-A1
1 Microphone 4 LED 'ONLINE' / Fault
2 Display 5 LED 'ON' / Operation
3 Configurable buttons S Key switch
You can create and print the button identification in '
PACE
-
Design
'.
9.1 Operating functions PTO2002/3-A1
Unlocking/locking the call station
Function Design
Unlocking call station
◈
Turn key switch with key to position 1 (horizontal)
Locking call station
◈
Turn key switch with key to position 0 (vertical)
9.2 Operation PTO2002/3-A1
The desk call station can’t be operated when the key switch is locked (position
0). The desk call station works in accordance with the following description
after having been unlocked with the key switch: Operation PT2001-A1 [➙ 30].
