10.3 Indicator PT2009-A1
Color Status Default Description
Zone
Button (3) is configured as 'Zone'
Green On - Zone is selected
Green On -
Zone is activated via the 'Talk' button and the station priority is
set to 1-7
Red On -
Zone is activated via the 'Talk' button and the station priority is
set to 8 or higher
Red On - Zone is activated via the 'PLAY Sound'
Red
Slow
blinking
-
Zone is activated via the 'Logic input' and the station priority is
set to 1-7
Red
Fast
blinking
-
Zone is activated via the 'Logic input' and the station priority is
set to 8 or higher
Yellow On - Zone fault during an alarm event
- Off x Zone is not selected and is not activated
Talk
Green On - Microphone is activated and played in selected zones
Green Blinking -
Microphone is in standby and pre-announcement tone is played
in selected zones
- Off x Microphone is not activated
PLAY Sound
Button (3) is configured as 'PLAY Sound'
Green On - Sound is active and played in selected zones
- Off x Sound is not activated
STOP Sound
Button (3) is configured as 'STOP Sound'
- Off x Always
