System status indicator (19") PT2004
-
A1
Operating functions PT2004-A1
13
44 | 57 A6V10430571_en--_c
13 System status indicator (19") PT2004-A1
1 'Operating / Betrieb' indicator 4 Speaker
2 'Fault / Störung' indicator 5
<Buzzer reset/Test –
Quittierung/Test> button
3
'Voice alarm / Sprachalarm'
indicator
13.1 Operating functions PT2004-A1
Function Design
Silencing a buzzer
Acknowledging a fault
warning
Performing a test
◈
Press the black <Buzzer reset/Test – Quittierung/Test> button
13.2 Operation PT2004-A1
Acknowledging a fault warning
w LED 'FAULT' lights up.
◈
Press <Buzzer reset/Test – Quittierung/Test>.
a LED 'FAULT' turns off.
a The buzzer has been silenced.
Performing a test
w No buzzer is active.
◈
Press <Silence Buzzer/LED Test> to test the function of the buzzer and all
LEDs.
Recurring fault messages
w The LED 'FAULT' lights up again.
w The fault in the system has not been rectified.
◈
Inform Siemens customer support.
a Request that maintenance be carried out by technical personnel.
