4.6 General settings
4.6.1 Actual configuration
The configuration parameters are only accessible and thus visible in controller stop
mode.
However, the selected configuration is copied to information parameters - called
actual configuration - that are visible in every controller state and can also be
checked via ABT Go / ABT Site.
Note
Inputs/outputs or devices marked as active indicate only that the corresponding
functionality or device is enabled, but not that the sensor or device is physically
connected and operational.
Favorite BACnet object Description
Actual configuration ActlCnf, STR_VIEW,80 Favorite structure containing the
actual configuration info/objects
Actual configurations for
control functions
Control functions and HVAC components BACnet object
Actual configuration for ventilation control ActlVntCtlCnf, MVAL,398
Actual configuration for temperature control ActlTCtlCnf, MVAL,393
Actual configuration for kitchen hood ventilation ActlKtchVntCnf, MVAL,394
Actual configuration for fireplace ventilation ActlFplcVntCnf, MVAL,395
Actual configuration for dehumidification control ActlDhuCtlCnf, MVAL,396
Actual configuration for air quality control ActlAqCtlCnf, MVAL,664
Actual configuration for particulate matter control ActlPmCtlCnf, MVAL,572
Actual configuration for outside air damper ActlDmpOaCnf, MVAL,403
Actual configuration for preheating coil ActlPreHclCnf, MVAL,401
Actual configuration for energy recovery ActlErcCnf, MVAL,402
Actual configuration for heating coil ActlHclCnf, MVAL,399
Actual configuration for cooling coil ActlCclCnf, MVAL,400
Actual configuration for fire damper ActlFdpCnf, MVAL,404
Actual configuration for dehumidifier ActlDhumCnf, MVAL,487
Actual configuration for
controller board
I/O BACnet object
Actual configuration for B1 ActlB1Cnf, MVAL,351
Actual configuration for B2 ActlB2Cnf, MVAL,352
Actual configuration for B3 ActlB3Cnf, MVAL,353
Actual configuration for B4 ActlB4Cnf, MVAL,354
Actual configuration for D1 ActlD1Cnf, MVAL,355
Actual configuration for D2 ActlD2Cnf, MVAL,356
Actual configuration for X1 ActlX1Cnf, MVAL,357
Actual configuration for X2 ActlX2Cnf, MVAL,358
Actual configuration for X3 ActlX3Cnf, MVAL,359
Actual configuration for X8 ActlX8Cnf, MVAL,360
Actual configuration for Q1 ActlQ1Cnf, MVAL,365
Actual configuration for Q2 ActlQ2Cnf, MVAL,366
Actual configuration for Q3 ActlQ3Cnf, MVAL,367
Actual configuration for A1 ActlA1Cnf, MVAL,432
Actual configuration for A2 ActlA2Cnf, MVAL,433
Configuration
General settings
4
A6V10733786_en_c 51 | 170
