4.5.2 Output settings
4.5.2.1 Controller board
The following functions can be selected for output signals on the controller board:
Outputs Q1, Q2, Q3
Parameter BACnet object
Selection for Q1 Q1Sel, STR_VIEW,61
Selection for Q2 Q2Sel, STR_VIEW,62
Selection for Q3 Q3Sel, STR_VIEW,63
Selection BACnet object R/W Signal type Range
None - - -
Outside air damper command DmpOaCmd R/W Relay NO
Fire damper command FdpCmd R/W Relay NO
Preheating coil electric command PreHclElCmd R/W Relay NO
Preheating coil pump command PreHclPuCmd R/W Relay NO
Earth-to-air heat exchanger bypass damper
command
EaHxDmpbCmd R/W Relay NO
Heat exchanger bypass damper command HExgDmpBypCmd R/W Relay NO
Electric heating coil command HclElCmd R/W Relay NO
Heating coil pump command HclPuCmd R/W Relay NO
Cooling coil pump command CclPuCmd R/W Relay NO
Cooling coil DX evaporator command CclDxCmd R/W Relay NO
Dehumidifier free-standing command DhumFrsdCmd R/W Relay NO
A-Alarm indication output AalmIndOut R/W Relay NO
B-Alarm indication output BalmIndOut R/W Relay NO
Common alarm indication output CmnAlmIndOut R/W Relay NO
Operation indication output OpIndOut R/W Relay NO
Heat exchanger bypass piston damper
Open*
HExgDmpBypCmdOp
BO,104 (Q1
R/W Relay NO
Heat exchanger bypass piston damper
Close*
HExgDmpBypCmdCls
BO,105 (Q2
R/W Relay NO
*Heat exchanger bypass piston damper Open / Close are co-dependent and
cannot be selected separately. For further details refer to chapter
Passive Heat Exchanger, controlled (PltHExg21y) [➙99].
Configuration
Configuring the hardware
4
44 | 170 A6V10733786_en_c
