Siemens CP 343-1 User Manual

CP 343-1
Manual, 12/2018, C79000−G8976−C201-08
25
Requirements for use
3
3.1
Operation in control device families
The CP can be operated in the following device families:
● S7-300 stations with the following CPU types:
– Standard
– Compact
– Modular
● C7 compact units in C7 packaging system
● SINUMERIK
The following tables show the device environment in which the CP can be operated with the
range of functions described here.
Note
The tables list the CPUs and devices released at
the time this manual went to print. CPUs of
the S7
-300 or C7 control systems released later and not listed in the tables can also handle
the range of functions described here.
Table 3- 1 Use of the CP with S7-300
CPU
Order number
CPU 312 6ES7 312-1AD10-0AB0
6ES7 312-1AE13-0AB0
6ES7 312-1AE14-0AB0
CPU 312C 6ES7 312-5BD00-0AB0
6ES7 312-5BD01-0AB0
6ES7 312-5BE03-0AB0
CPU 312 IFM 6ES7 312-5AC02-0AB0
6ES7 312-5AC82-0AB0
CPU 313
6ES7 313-1AD03-0AB0
CPU 313C 6ES7 313-5BE00-0AB0
6ES7 313-5BE01-0AB0
6ES7 313-5BF03-0AB0
CPU 313C-2 DP 6ES7 313-6CE00-0AB0
6ES7 313-6CE01-0AB0
6ES7 313-6CF03-0AB0
CPU 313C-2 PtP 6ES7 313-6BE00-0AB0
6ES7 313-6BE01-0AB0
6ES7 313-6BF03-0AB0

Siemens CP 343-1 Specifications

General

Product Type Designation	CP 343-1
Power Supply	24 V DC
Protection Class	IP20
Product Type	Communications processor
Interface	Ethernet
Data Transmission Rate	10/100 Mbit/s
Protocols Supported	TCP/IP, UDP
Number of Ports	1
Operating Temperature	0 to 60 °C
